Antenna Bases & Mounts

Please call or e-mail us 24/7 for Sales, Service & Antenna Bases, Mounts, Springs & Adapters Support.

We are happy to provide technical advice to help you find the best solution for your requirements at No charge anytime!
Call us direct for current pricing and freight costs. - Payment by credit card or by EFT.

BMB  "Bonnet Mount Black"
The very BEST Bonnet & Boot Mount EVER!

BMB Side (showing rubber feet)

BMB on Car (7 Years No Damage at all)

BMB Underside (showing grubs screws)

The BMB or BMS is the best choice when mounting a monopole style antenna to a vehicle as it mounts the antenna very close to the ground plane ensuring the very best SWR and radiation pattern, this is especially important with regards to UHF antennas such as S474, M474, M475, M476 etc as mounting these antennas onto z brackets can cause a poor SWR due to the raising of the antenna too high over the bonnet.

1. The powder coated black (BMB) or the stainless steel boot mount polished (BMS) will fit most vehicles bonnets and boots

2. The Mobile One BMB is strong and efficient, simple to use, secure, no drilling holes and is quick to remove with an allen key


           Pros - There is nothing else like it for performance for a very low SWR              Cons - The angle of your bonnet or boot may be a too greater angle!



Price = $49.00
5/16" Antenna Mounts
$19.00
$25.00
$29.00

$19.00

$19.00



$5.00
1. BASEUB 2. BASEUL 3. BASEBSS 4. SO516 5. SA516 6. MICLIP
  1. BASEUB = A light duty HF / UHF Antenna base to suit all 5/16" based antennas from 1MHz to 600MHz and up to 1500mm long
  2. BASEUL = A light duty HF / UHF Antenna base to suit all 5/16" based antennas from 1MHz to 600MHz and up to 1500mm long - (Aussie parts Aussie Made)
  3. BASEBSS = Heavy Duty HF Antenna Base to suit Antennas 1MHz to 30Mhz - 5/16" x 26tpi ... with any BB4 / 5 / 6 mounting bracket.
  4. SO516 = Heavy Duty Base to suit Antennas 1MHz to 300Mhz - 5/16" x 26tpi ... with any BB4 / 5 / 6 mounting bracket.
  5. SA516 = Slope Adjuster suit 5/16” antenna bases - suitable for most antennas up to 1200 mm with up to 30 degrees of adjustment.
  6. MICLIP = Microphone Clip S/Steel complete with mounting screws.

Vehicle and Base Antenna Mounts


$9.00
$15.00

$15.00
$22.00 $24.00
1. LMBL 2. MMBH 3. BBL 4. BBU 6. BB4/5/6/7 45/50/63/70mm
  1. LMBL = L’ Mounting Bracket Light Duty - 1mm S/Steel with 16mm hole and suitable for various mounting options including mast, pole or caravan side mount (suitable for Dipole Mount, BASEUB, BASESS Light Duty bases + ALL antennas up to DX160 / M160)
  2. MMBH = Mirror Mount Heavy Duty Bracket -3mm S/Steel with mounting hardware (suitable for BASEUB, BASESS, SAM or SAMS bases + ALL antennas up to DX270ASAM)
  3. BBL = Bull Bar ‘L’ Heavy Duty Bracket with 3mm thick S/Steel complete with ‘U’ bolts - (suitable for BASEUB, BASESS, SAM or SAMS bases + ALL antennas up to DX270ASAM) will clamp bars from 40mm to 52mm
  4. BBU = Bull Bar ULTRA Heavy Duty BOX Bracket -2.5mm S/Steel with Worm Drive clamp (suitable for SAM or SAMS bases + ALL antennas up to DX270ASAM as well as Hamtennas) - will clamp bars from 40mm to 60mm.
  5. BB4/5/6/7 = Heavy Duty Bracket -3mm S/Steel with mounting hardware (suitable for BASEUB, BASESS, SAM or SAMS bases + ALL antennas up to DX270ASAM)
1/2" Antenna Mounts
sam
$65.00




$59.00
sam2s
$69.00
samn
$69.00

$29.00
1. SAM 2. SAMS 3. SAM2S 4. SAMN 5. SOC2S
  1. SAM = Extra Heavy Duty antenna mount for 1/2" based antennas 1MHz to 55MHz with side entry SO239 to suit PL259 Connector
  2. SAMS = Extra Heavy Duty antenna mount for 1/2" based antennas 1MHz to 55MHz with bottom entry SO239 to suit PL259
  3. SAM2S = Extra Heavy Duty antenna mount for UHF Ground independent CB Antennas with top and side entry SO239's to suit PL259
  4. SAMN = Extra Heavy Duty antenna mount for any frequency antenna with FME side entrance and N type connector on top
  5. SOC2S = Double SO239 bulkhead with a 10mm thick delrron spacer & lock washer - for all antennas that have a PL259 connection HF,VHF & UHF
Antenna Springs for 5/16" & 3/8" Bases



$19.00

$29.00



$45.00




$55.00


1. SAS 2. SAL 3. SAO 4. SS3812
  1. SAS = 60mm long Heavy Duty barrel spring for 5/16" antennas up tp 80cm long
  2. SAL = 80mm long Heavy Duty barrel spring for 5/16" antennas up to 100cm long
  3. SAO = 50mm long Heavy Duty very rigid spring for 5/16" all antennas up to 150cm long
  4. SS3812 = Stainless steel spring with US Female 3/8” to BSW Female 1/2” and suitable for USA type male 3/8” antennas. Compatible with SAM & SAMS bases.
Antenna Springs for 1/2" Bases










$66.00










$60.00





$89.00











$131.00






$115.00




$125.00
$144.00
1. SS
Super Spring
2. SSL
  Super Spring Large
3. SSU
  Super Spring Ultra
4. SS + SAM
Super Spring
5. SSL + SAMS
  Super Spring Large
6. SSL + SAM
  Super Spring Large
7. SSU + SAMS
  Super Spring Ultra
  1. SS = Heavy Duty Stainless Steel Spring 60mm high to suit 1/2" Base Antennas and SAM mounts.
  2. SSL = Extra Heavy Duty Stainless Steel Barrel Spring 100mm high to suit 1/2" Base Antennas and SAM mounts.
  3. SSU = Ultra Heavy Duty Stainless Steel Barrel Spring 130mm high to suit 1/2" Base Antennas and SAM mounts, Also available in BLACK
  4. SS+SAM = Heavy Duty Stainless Steel Barrel Spring combined with the heavy duty SAM mount, total height is 110mm.
  5. SSL+SAMS = Extra Heavy Duty Stainless Steel Barrel Spring combined with the heavy duty SAMS mount, total height is 150mm.
  6. SSL+SAM = Extra Heavy Duty Stainless Steel Barrel Spring combined with the heavy duty SAM mount, total height is 150mm.
  7. SSU+SAMS = Ultra Heavy Duty Stainless Steel Barrel Spring combined with the heavy duty SAMS mount, total height is 180mm.

Antenna Adapters & Gender Changers
RAF DF12 MAF MA MMS RAS M516 M38 M12 PLA







$8.00 $8.00 $9.00 $5.00 $12.00 $19.00 $3.00 $8.00 $5.00 $24.00
3/8" Female to 5/16" Female 1/2" Female to 1/2" Female 3/8” Male to 5/16” Female 3/8" Male to 5/16" Male 1/2" Male to 5/16" Male 1/2" Female to 5/16" Male 5/16"x 25mm long Brass Male stud. 3/8" x 25mm long Stainless Steel Male stud. 1/2" x 30mm long Stainless Steel stud. PL259 to 5/16" Male
PLEASE NOTE: 5/16" is a 26tpi machine thread - 1/2" is a BSW thread and a 3/8" is a 24tpi UNF thread
PLEASE NOTE: All these adapters can be interchangeable to make a mutltude of Adaptions.
